FC(Fuel Cell) Inverter

440kW(PAFC์šฉ)/10kW(SOFC์šฉ)

Destin Power's fuel cell inverter utilizes High Thermal Performance PEBB with Hybrid SiC, boasting a maximum voltage of 1200V and a high efficiency of 98%. Furthermore, HOC is possible through real-time monitoring of operating hours, enabling the creation of fuel cell big data.



High reliability thanks to core power conversion modules.

System design based on a 20-year lifespan.

Mitsubishi 1700V Hybrid SIC IGBT Module.

High efficiency - rated operating efficiency of over 98%

Ensure high performance power quality
Ultra-fast switching compensation operation within 4ms
Applying P+R (resonance) control - instantaneous waveform control
Nonlinear load control performance: 3% or less standard, nonlinear load voltage THD
Unbalanced load control performance 100% unbalanced load voltage of +-3% or less

Real-time remote monitoring and diagnostics

Equipped with an exclusive built-in power manager

Supports stable communication lines - Dual Gigabit Ethernet Ports

HYDEN FC 440(PAFC), 10(SOFC)Specification

Model
Unit
FC 440(PAFC)
FC 10(SOFC)
DC Input
DC Operating range
V
750V~1200V
350V~600V
Max allowable DC Voltage
V
1200V
600V
Max. DC Current
V
705V
26A
DC Terminals
ea
P : 1ea, N:1ea
+ 1ea, - 1ea
AC Output
Gross AC Power(565kVA, PF=0.85)
V
480
380(± 10%)
Grid Voltage
V
480 V (3 phase 3 wire)
 (3 phase 4 wire)
AC operating voltage range
A
± 5%
15.2A
Max Rated Current
kW
715 A

Rated frequency
Hz
50 & 60 Hz
60 Hz
THD
-
Less than 3% at rated power
Less than 5% at rated power
Power factor cosφ (@ rated)
-
1

cosφ range
%
0.85 ~ -0.85

Efficiency
Max.Efficiency
%
98%
97%
Operating Condition
Ambient Temperature
 โ„ƒ
-20.2 ~ + 104 โ„‰ (-29 ~ + 40 โ„ƒ)
-10 ~ + 60โ„ƒ
Temperature for Storage
 โ„ƒ
-20.2 ~ + 158 โ„‰ (-29 ~ + 70 โ„ƒ)
-20 ~ + 70โ„ƒ
Relative Humidity
0 ~ 95 % (Non-condensing)
0 ~ 95 % (Non-condensing)
Max. height above sea-level
2,000 m
1,000 m
Cooling Method
Forced Air Cooling
๊ฐ•์ œ ๊ณต๋žญ์‹
Noise Level
< 80 dB

IP Protection Class
NEMA 1

Enclosure
Dimension (W x H x D)
-
82.25 x 84.03 x 54.75 Inch,(2089.15 x 2130.4 x 1390.65 mm)
IP20
Weight

4,850 lb (2,200 kg)

Communication
Default
-
Modbus RTU or CAN / Modbus TCP
Optional
-
Modbus TCP / DNP3.0, IEC61850
Monitoring Device
TFT LCD Touch screen
Standards
EMC
-
FCC Class A
Safety
-
TUV-SUD
Functionality
Emergency Stop
-
Yes

Over Voltage Protection DC / AC
-
Yes/Yes


The specifications and appearance images of this product may change in the future.
